Description
CODE | 1 DAY | WEEKLY |
C512WW | $400.00 | $1600.00 |
Long Term Hires available – please call us to arrange this
Safety Gear Required:
Vehicle Required:
Vehicle must have at least 3.0 ton braked tow rating
Description:
Named after the ancient Greek goddess of wisdom and strength, Athena was named for its clever bi-levelling capacity. The ATHENA 850 is at the pinnacle of access technology.
The ATHENA performs the work of scaffolding, slab scissors and an all-terrain unit in one cost effective and convenient machine, negating the need to have multiple machines on site. Intelligent monitoring systems coupled with state of the art engineering come together to offer trades and industry a safer alternative for work on slopes and on slight inclines in tight access situations.
- Platform height: 6.5m
- Platform capacity (SWL): 250kg
- Height 2.38m
- Stowed Height (with folded railings): 1.98m
- Weight 1990kg
- Self levels up to 20 degree inclines
- Independently levelling tracks
- 6.1 m Moving height
- Automatic basket levelling
- Longitudinal levelling front +/- 16 degrees
- Longitudinal levelling rear +/- 20 degrees
- Lateral levelling +/- 15 degrees
- Gradeability 25 degrees
- Side slope 21 degrees
- Length: 2.14m
Specification Sheets and instructions for use below:
YRCO Product Brochure Athena 850 BL and HE
